Digital
Flat-bed Printer (Solvent
ink type) |
Model
Name |
GL-3 |
|
Head Type |
Micro Piezo 8 Channel Head |
Color
(
8 Colors ) |
Cyan,
Magenta, Yellow, Black, Light black, Light
light black, Light magenta,Light cyan |
Max. Printing Size |
329 mm x 600 mm |
Maximum Material Thickness |
100mm / 150 mm |
Printing Type |
Flatbed movement type |
Power Consumption |
AC 220V ±10%, 6A |
Interface And Connectivity |
USB 2.0 / WiFi / Ethernet (10/100 Base-T) |
Computer Operating System |
Microsoft Windows 8 / 7 / XP |
Output S/W |
Illustrator
/ Coreldraw / Software Rip, etc |
Resolution / Printing Speed |
720 x 720 dpi / 60sec (320 x 210mm, Oneway)
1440 x 720 dpi / 1Min 50sec (320 x 210mm, Oneway) 1440 x 1440 dpi / 3Min 30sec (320
x 210mm, Oneway) |
Environmental Conditions |
Temperature 16~29C, Humidity 20~80% RH |
Editing S/W |
Photoshop, Coreldraw, Illustrator, Partner Rip |
Warranty |
1 year |
Weight |
70Kg (Net) |
|
