Specification |
 |
Aluminum
substrate |
Electrochemically
grained and anodized aluminum substrate |
| Gauge |
0.15 , 0.30 mm |
| Maximum width |
1,420 mm |
| Spectral
sensitivity |
790-840nm Red Laser
Diode |
| Sensitivity |
120mj/§²(+10%) |
| Developer |
Kodak-Goldstar
Premium and similar developers |
| Dilution rate |
¡¡ |
| Temperature |
23¡É - 26¡É |
| Developing time |
30 seconds +- |
| Dot resolution |
1-99%(250LPI) |
| Replenishment rate |
80 - 125ml/§³ |
| Run length |
before
burning 100,000 |
| Safe light |
|
| Shelf life |
12
month. It must be kept in cool and dry place.
It must be kept in cool and dry place.
Temperature : 5~25¡É Humidity
: 50% |
