| Specification |
 |
Aluminum
substrate |
Electrochemically
grained and anodized aluminum substrate |
| Gauge |
0.15 , 0.30 mm |
| Maximum width |
1,420
mm |
| Spectral
sensitivity |
365~436
nm (UV radiation), 365-375nm & 405-410 UV laser |
| Sensitivity |
50
- 60 mj/§²(Ugra step3, Fuji
step4) |
| Developer |
Acceptable
all developer (like Fuji-DP4, Agfa EP-350) |
| Dilution rate |
1
: 4 - 1 : 5 (using Fuji-DP4) |
| Temperature |
23
- 26 ¡É |
| Developing time |
20-30
seconds |
| Dot resolution |
2-99%
(200LPI) |
| Replenishment rate |
¡¡ |
| Run length |
before
burning more than 60,000
after burning 150,000~300,000 |
| Safe light |
safe
yellow light |
| Shelf life |
12
-18 month
It must be kept in cool and dry place.
Temperature : 5~25¡É Humidity
: 50% |
|
|
 |
 |
